0.75 HP Square Flange Full Rated Pool Pump Motor, 1.65 SF

Arriving under the specification of 0.75 HP and 1.65 SF, this motor is a star among the mechanical devices. No more concern about pumping water as you have the apt device for life-long utilization. Cheap and reliable, as most customers expect!

Product Features:

Square flange full rated switchless pool pump motor

Stainless steel shaft for corrosion protection

Sealed ball bearings

Permanent split capacitor for enhanced running efficiency

Pump motor has a threaded shaft that allows for convenient and direct mounting

Additional Features:

Output HP: 3/4

Frequency: 60 Hz

Current: SF 6.5/13.0 A

Service factor: 1.65

Frame: P56Y

Output KW: 0.56 kW

Voltage: 230/115 V

Speed: 3450 rpm

Phase: 1

Insulation class: F

Enclosure: drip proof

Ambient temperature: 50°C

Electrical type: permanent split capacitor, single or dual voltage

Rotation: counterclockwise pump end

Motor orientation: horizontal

Opp drive end bearing: ball

Shaft type: threaded

Mounting: square flange

Drive end bearing: ball

Dimensions:

Shaft diameter: 0.62″

Frame length: 8″

Shaft extension: 0.91″

Material(s): rolled steel/stainless steel
